DuPont™ Tychem® 10000
TK613T LY

DuPont™ Tychem® 10000 Encapsulated Level A Suit. Certified to NFPA 1990 (NFPA 1992), 2022 edition. Expanded Back, Rear Entry. Extra-Wide, Anti-Fog, Three-Layer Faceshield: 40 mil PVC / 5 mil Teflon™ / 20 mil PVC. Attached Dual Layer Gloves, Internal: Multi-layer laminate / External: Neoprene. Attached Socks with Outer Boot Flaps. Double Storm Flap with Hook & Loop Closure. Two Exhaust Valves. Double Taped Seams. Lime Yellow.Quantity/box: 1 per case

Fit in a Range

Download Master File

Selling Tips

Media, web, pictures & literature

Product Info & Wear Trials

Click circles to show off details

More Technical Information and datasheet

Catalogs & Codes

Reference:

SKU	Size	D-code	Option Code
TK613TLYMD000100	MD	D13492120	Standard
TK613TLYLG000100	LG	D13492113	Standard
TK613TLYXL000100	XL	D13492135	Standard
TK613TLY2X000100	2X	D13492093	Standard
TK613TLY3X000100	3X	D13492102	Standard
TK613TLY4X000100	4X	D14436821	Standard

Benefits, Features & Applications

Features:

Tychem® 10000 exhibits excellent chemical barrier properties and offers an extremely durable fabric that is puncture- and tear-resistant. Tychem® 10000 fabric shows at least 30 minutes of barrier protection to 322 challenge chemicals with no observed breakthrough.

Applications:

Tychem® 10000 is specifically developed for protection against toxic, corrosive gases, liquids and solid chemicals. This high-performance chemical barrier fabric is suited for industrial, HazMat, and domestic preparedness applications.

Benefits:

Certified to NFPA 1990 (NFPA 1994, Class 2) 2022 edition
Class 2 garments are designed for situations where there is an immediate danger to life and health (IDLH) and must be worn with a self-contained breathing apparatus (SCBA).
Encapsulated Level A garment design is our highest level of protection from liquid splash and vapor/gas exposures for both the wearer and respiratory equipment
Double taped seams provide strong chemical resistance against heavy liquid splashes. A sewn seam is covered, both inside and outside of garment with compatible chemical-resistant material by heat-sealing.
Expanded anti-fog faceshield provides wide 220 degree viewing angle. EX faceshield is three-layer laminate composed of 40 mil PVC/5 mil Teflon™ / 20 mil PVC
Rear entry design keeps closure away from direct contact with frontal chemical exposure and provides ability to change air bottle on SCBA without removing the entire garment
Expanded back to accommodate self-contained air breathing apparatus (SCBA)
Vapor tight zipper. Extra long to increase garment opening and aid donning and doffing
Storm flap covers zipper which can be secured by the wearer with rugged hook and loop material to prevent intrusion at zipper
Attached internal gloves composed of five layer laminate film for a broad range of chemical protection
Neoprene gloves provide mechanical and physical durability to help protect inner gloves
Integrated socks composed of garment material
Attached flaps are designed to cover boot tops to help reduce potential for liquid intrusion
Two exhaust valves release higher pressure inside encapsulating garments while simultaneously helping to prevent inward leakage of external vapors or particles into the garment. One-way valves are positive pressure and open on demand. Valves include splash covers made of barrier material to help prevent liquid intrusion. Valves are located on left back of head and right lower back. (146)
Internal adjustable waist belt system for support and improved fit
Each suit has a unique serial number and is fully tested at time of manufacture including positive air pressure integrity testing per ASTM F1052.
Manufactured under specifications that do not contain natural rubber latex
Pass-thrus are optional and can be installed upon request when ordering. Some suits are available with optional pass-thrus to accommodate the following SCBA manufacturers: Scott, Interspiro, MSA, Draeger, Survivair®. Please call Customer Service 1-800-931-3456 for additional information. (3377)
Made in the USA, North American Free Trade Agreement (NAFTA) compliant and Trade Agreement Act (TAA) compliant

Selling Tips

Tychem® 10000

Premium protection against toxic and corrosive gas, liquid and solid chemicals as well as chemical warfare agents
Leading garment chosen by hazmat responders worldwide for CBRN response
Extremely durable, puncture- and tear-resistant fabric
Wide range of garment styles, including totally encapsulated, vapor protective Level A and liquid-splash protective Level B suits
Provides at least 30 minutes of protection against >320 chemicals
Tychem® TK612T/613T certified to NFPA 1994 Class 2
Lime yellow for high visibility
Encapsulated Tychem® 10000 suits are shipped in a storage tote with a color-coded handle: • Red handle = Level A • Silver handle = certified Level A • Blue handle = Level B • Yellow handle = training
