DuPont™ Tyvek® 500 HP
TY178S HP

Reference:

Features:

Workers operating with a full-body harness in environments where hazardous particle or light liquid aerosol hazards are present, previously had to compromise between efficient personal protection* and protecting their full-body harness against external contamination.

The new Tyvek® 500 HP TY178S HP garment offers a unique solution – protection of both the wearer and the full-body harness – by providing a barrier between the user and the particle or light liquid aerosol hazards* in the environment. Designed to be worn over a full-body harness, the innovative, patent-pending garment design allows workers to access and utilize multiple D-Rings on their full-body harness while providing an ideal balance of protection, durability, and comfort.

This new TY178S HP model has four attached sleeves for use with front, back and side D-Rings of a full-body harness. The off-centered zipper entry allows accommodating the front D-Ring sleeve for front D-Ring connection. *The user must ensure the garment is suitable for the chemical hazard before use. Please refer to chemical permeation data available in SafeSPEC™ to help you understand the level of protection the garment offers.

Applications:

Compatible with a variety of full-body harness models, this garment may be used for a wide range of applications including painting, cleaning, maintenance, and more.

Benefits:

• Innovative, patent-pending design for applications where full-body harness is worn; garment is designed to be worn over the full-body harness
• Multiple access points to the full-body harness through the four elasticized D-Ring sleeves that are attached to the garment - one in the front, one in the back, and one on each side of the garment
• Off-centered zipper entry to accommodate the front D-Ring sleeve for front D-Ring connection
• Certified according to Regulation (EU) 2016/425.
• Chemical protective clothing, Category III, Type 5-B and 6-B.
• EN 14126 (barrier to infective agents), EN 1073-2 (protection against radioactive contamination).
• Antistatic treatment (EN 1149-5) – on both sides of the fabric
• 3-piece hood with elastic face opening
• Stitched seams
• Tyvek® thumb loops
• Pin locking slider locks in place when the pins on the puller are pushed into the zipper elements
• Tyvek® storm flap
• Elasticated ankles & wrists and elasticated (glued-in) waist
• Ample crotch area
• Manufactured under specifications that do not contain silicone or silicone oils
• Dynamic Fall Test with an articulated mannequin – Tested in an independent testing laboratory as well as at a harness manufacturer with a conclusion that the Tyvek® 500 HP TY178S HP garment is not anticipated to affect the dynamic fall test performance of the full-body harness when worn underneath this garment. The test is successful as it demonstrated that the Tyvek® 500 HP TY178S HP garment is not impairing the proper function of the full-body harness in case of a fall.
